100KW High Voltage Energy Power System Lithium Battery All One System
Efficient and Reliable Energy Solution
Our 100kW-115kW High Voltage Lithium Battery Energy Power System is the ultimate solution for commercial solar power applications. Designed to seamlessly integrate with various energy storage systems, this all-in-one system provides reliable and efficient energy storage for businesses, EPC companies, and large-scale projects. Equipped with advanced lithium battery technology, it ensures optimal performance, safety, and longevity, making it a premier choice for energy storage and commercial power needs.
|
DC SIDE |
|
|
Max. Recommended PV array power |
100 kW |
|
Max. usable PV input power (ESS DC side) |
96 kW |
|
Max. PV input voltage (ESS DC side) |
1000 V |
|
Start-up voltage (ESS DC side) |
180 V |
|
Rated PV input voltage (ESS DC side) |
650 V |
|
MPPT voltage range (ESS DC side) |
160–950 V |
|
No. of MPP trackers / strings per MPP tracker (ESS DC side) |
5 / 2 |
|
Max. input current per MPPT (ESS DC side) |
40 A |
|
Isc PV array short circuit current per MPPT (ESS DC side) |
50 A |
|
AC SIDE |
|
|
Rated output power (ESS AC side) |
50.0 kW |
|
Rated output current (ESS AC side) |
75.8 A @ 220 V; 72.5 A @ 230 V |
|
Max. apparent power (ESS AC side) |
55.0 kVA |
|
Max. output continuous current (ESS AC side) |
83.4 A @ 220 V; 79.8 A @ 230 V |
|
Nominal AC voltage (ESS AC side) |
3 / N / PE, 220 / 380 V; 3 / N / PE, 230 / 400 V |
|
Rated AC frequency (ESS AC side) |
50 Hz / 60 Hz |
|
Adjustable power factor range (ESS AC side) |
~1 (0.8 leading ~ 0.8 lagging) |
|
THDi (rated power, ESS AC side) |
<3% |
|
BATTERY SIDE
|
|
|
Battery type (ESS battery side) |
LFP / 280 Ah |
|
Rated battery capacity (ESS battery side) |
100 kWh |
|
Rated battery voltage (ESS battery side) |
358.4 V |
|
Battery voltage range (ESS battery side) |
296.8–408.8 V |
|
Rated charge / discharge current (ESS battery side) |
140 A |
|
GENERAL PARAMETERS
|
|
|
Dimensions with inverter (W × H × D, ESS) |
1514.5 × 1163.6 × 1597 mm |
|
Dimensions without inverter (W × H × D, ESS) |
1130 × 1163.6 × 1597 mm |
|
Weight with inverter (ESS) |
1287.5 kg |
|
Weight without inverter (ESS) |
1214.5 kg |
|
Operation temperature range (ESS) |
-20℃–55℃ (Power derating 45℃+) |
|
Relative humidity (ESS) |
0–95% |
|
Max. operation altitude (ESS) |
≤3000 m (Power derating 2000 m) |
|
Cooling concept (ESS) |
Smart air cooling |
|
Ingress protection (ESS cabinet) |
IP54 |
|
Fire protection (ESS) |
Aerosol |
|
Topology (ESS) |
Non-isolated |
|
Certifications (ESS) |
IEC62619, EN62477, IEC63056, IEC61000, UN38.3 |
|
INVERTER |
|
INPUT DC (PV side)
|
|
|
Recommended max. PV array size (Inverter PV side) |
100 kW |
|
Max. usable PV input power (Inverter PV side) |
96 kW |
|
Max. input voltage (Inverter PV side) |
1000 V |
|
Rated voltage (Inverter PV side) |
600 V |
|
Start-up voltage (Inverter PV side) |
180 V |
|
MPPT voltage range (Inverter PV side) |
150–850 V |
|
Max. input current (Inverter PV side) |
4 × 40 A |
|
Max. short circuit current (Inverter PV side) |
4 × 60 A |
|
MPPT number / Max. input strings number (Inverter PV side) |
4 / 8 |
Battery
|
|
|
Battery type (Inverter) |
Li-ion |
|
Battery voltage range (Inverter) |
150–800 V |
|
Max. charge / discharge power (Inverter) |
55 kW |
|
Max. charge / discharge current (Inverter) |
70 A × 2① |
|
Number of battery ports (Inverter) |
2 |
|
Max. charge / discharge power of each input (Inverter) |
35 kW |
|
Communication (Inverter battery side) |
CAN / RS485 |
|
Note: ① Supporting parallel 140 A input |
|
Output AC (Grid side) |
|
|
Rated output power (Inverter grid side) |
50 kW |
|
Max. apparent output power (Inverter grid side) |
50 kVA |
|
Rated grid voltage (Inverter grid side) |
3/N/PE, 220/380 V, 230/400 V |
|
Rated grid frequency (Inverter grid side) |
50 Hz / 60 Hz |
|
Rated grid output current (Inverter grid side) |
76 A / 72.2 A |
|
Max. output current (Inverter grid side) |
76 A / 72.2 A |
|
Power factor (Inverter grid side) |
> 0.99 (0.8 lead–0.8 lag) |
|
THDi (Inverter grid side) |
< 3% |
INPUT AC (Grid Side）
|
|
|
Max. AC passthrough current (Inverter AC input) |
152 A / 144.4 A |
|
Rated input voltage (Inverter AC input) |
3/N/PE, 220/380 V, 230/400 V |
|
Rated input frequency (Inverter AC input) |
50 Hz / 60 Hz |
Input Generator |
|
|
Max. input power (Generator input) |
50 kW |
|
Rated input current (Generator input) |
76 A / 72.2 A |
|
Rated input voltage (Generator input) |
3/N/PE, 220/380 V, 230/400 V |
|
Rated input frequency (Generator input) |
50 Hz / 60 Hz |
Output AC (Back-up)
|
|
|
Rated output power (Back-up output) |
50 kW |
|
Max. apparent output power (Back-up output) |
1.6 × rated power, 2 s |
|
Back-up switch time |
< 10 ms |
|
Rated output voltage (Back-up output) |
3/N/PE, 220/380 V, 230/400 V |
|
Rated frequency (Back-up output) |
50 Hz / 60 Hz |
|
Rated output current (Back-up output) |
76 A / 72.2 A |
|
THDv (@ linear load, Back-up) |
< 2% |
Efficiency |
|
|
Max. efficiency (Inverter) |
97.8% |
|
EU efficiency (Inverter) |
97.4% |
|
BAT charged by PV max. efficiency |
98.5% |
|
BAT charged / discharged to AC max. efficiency |
97.5% |
Protection |
|
|
Anti-islanding protection |
Yes |
|
Output over current protection |
Yes |
|
Short circuit protection |
Yes |
|
Integrated DC switch |
Yes |
|
DC reverse-polarity protection |
Yes |
|
Surge protection |
DC Type II / AC Type II |
|
Integrated AFCI 2.0 |
Optional |
General Data |
|
|
Dimensions (W × H × D, Inverter) |
530 × 880 × 290 mm |
|
Weight (Inverter) |
73 kg |
|
Topology (Inverter) |
Transformerless |
|
Self-consumption (night, Inverter) |
< 35 W |
|
Operating ambient temperature (Inverter) |
-25–+60℃ |
|
Relative humidity (Inverter) |
0–100% |
|
Ingress protection (Inverter) |
IP66 |
|
Cooling concept (Inverter) |
Intelligent fan-cooling |
|
Max. operation altitude (Inverter) |
4000 m |
|
Grid connection standard |
G99, VDE-AR-N 4105/VDE V 0124, EN 50549-1/-10 |
|
Safety / EMC standard |
IEC/EN 62109-1/-2, IEC/EN 61000-6-2/-4, EN 55011 |
Connection and Communication
|
|
|
PV connection |
MC4 quick connection plug |
|
Battery connection (Inverter) |
Terminal connector |
|
AC connection (Inverter) |
Terminal block |
|
Display |
7.0″ LCD display & Bluetooth + APP |
|
Communication (system) |
CAN, RS485, Ethernet, Optional: Wi-Fi, Cellular, LAN |
|
Battery Pack |
|
|
Battery type (Battery Pack) |
LFP 280 Ah |
|
Battery capacity (Battery Pack) |
14.336 kWh |
|
Battery configuration (Battery Pack) |
1P16S |
|
Rated battery voltage (Battery Pack) |
51.2 V |
|
Battery voltage range (Battery Pack) |
44.6–57.6 V |
|
Weight (Battery Pack) |
115 kg |
|
Charge / Discharge rate (Battery Pack) |
≤ 0.5C |
|
Dimensions (W × H × D, Battery Pack) |
420 × 730 × 230 mm |
|
Ingress protection (Battery Pack) |
IP20 |
Key Features
-
High Voltage Efficiency: This energy power system operates at high voltage levels, optimizing the transfer of energy from solar panels to the storage system. It reduces energy loss and enhances the overall efficiency of your solar power setup.
-
Power Range Options: Available in 100kW and 115kW configurations, this system caters to diverse commercial energy requirements. Whether you need to power a small business or a large-scale facility, our system has the flexibility to meet your needs.
-
Advanced Lithium Battery Technology: Utilizing state-of-the-art lithium-ion batteries, this energy storage system offers superior energy density, longer cycle life, and enhanced safety features compared to traditional lead-acid batteries. It's ideal for businesses looking to invest in long-term energy solutions.
-
All-in-One System: The integrated design combines the battery storage, inverter, and energy management system into a single, compact unit. This reduces installation complexity and space requirements, making it a cost-effective solution for EPC companies and commercial installations.
-
Commercial Solar Power Integration: Specifically engineered to work with commercial solar power systems, our energy power system can store excess solar energy generated during the day for use during peak demand periods or at night, significantly reducing energy costs.
-
Seamless Energy Storage: Perfect for commercial energy storage applications, this system allows businesses to store and use energy as needed, providing a reliable backup during grid outages and helping to maintain operational continuity.
-
Scalability: Designed for scalability, this energy storage system can be expanded to accommodate future energy needs, making it a future-proof investment for growing businesses and commercial operations.
-
EPC Company Friendly: Our system simplifies the process for EPC companies, offering easy integration with existing energy infrastructures and providing robust support for project planning and implementation.
Benefits of the 100kW-115kW High Voltage Lithium Battery Energy Power System
-
Energy Independence: Achieve greater energy independence by utilizing stored solar power during peak hours or when the grid is unavailable, reducing reliance on traditional energy sources and fluctuating energy prices.
-
Cost Savings: By storing energy when prices are low and using it when demand and prices are high, businesses can significantly cut energy costs. This system enables efficient demand charge management, further reducing operational expenses.
-
Sustainable Energy Solution: Investing in a high-voltage lithium battery storage system supports your business's sustainability goals by promoting the use of renewable energy and reducing carbon footprint.
-
Reliable Power Supply: Ensure your business operations remain uninterrupted with a dependable backup power supply that activates automatically during grid outages or power fluctuations.
-
Optimized Performance: The system’s integrated energy management features allow for real-time monitoring and optimization of energy use, ensuring your solar power and storage systems are always operating at peak efficiency.
-
Flexible Applications: Ideal for a range of commercial settings, including manufacturing plants, office buildings, and retail facilities, our energy storage system supports diverse applications and can be customized to meet specific energy needs.
Technical Specifications
- Power Output: 100kW / 115kW
- Battery Type: Advanced Lithium-ion
- Voltage Range: High Voltage Configuration
- Energy Storage Capacity: Customizable based on project requirements
- Inverter Integration: Built-in, compatible with various commercial solar power systems
- Communication Protocols: Supports Modbus, CAN, and other industry-standard protocols for seamless integration with energy management systems
- Safety Features: Overcharge, over-discharge, short circuit, and thermal protection
- Operational Temperature Range: -10°C to 50°C
Applications
-
Commercial Solar Power Systems: Enhance your solar power installation with efficient energy storage, allowing for better energy management and increased return on investment.
-
EPC Company Projects: Simplify project planning and installation with our all-in-one, scalable energy storage solution, perfect for large-scale commercial projects.
-
Battery Storage Facilities: Use as a standalone battery storage solution for energy arbitrage, peak shaving, and grid support.
-
Manufacturing and Industrial Sites: Provide a reliable backup power source to ensure uninterrupted operations in case of grid instability or outages.
-
Office Complexes and Retail Spaces: Reduce energy costs and ensure continuity of business operations with integrated energy storage and power management.
Why Choose Our Energy Storage System?
1. Expertise in Energy Solutions
With years of experience in the energy sector, we provide top-of-the-line energy storage systems tailored to meet the needs of businesses and EPC companies.
2. Quality and Reliability
Our products are built to last, using high-quality materials and cutting-edge technology to ensure consistent performance and safety.
3. Comprehensive Support
From consultation and design to installation and maintenance, we offer end-to-end support for your energy storage project.
4. Customizable Solutions
We understand that every business has unique energy requirements. Our systems are customizable to meet specific needs, ensuring maximum efficiency and return on investment.
Frequently Asked Questions (FAQs)
Q: How does this energy storage system integrate with existing commercial solar power systems?
A: Our energy storage system is designed to seamlessly integrate with existing commercial solar power installations. It features built-in inverters and energy management systems that are compatible with a wide range of solar setups, allowing for easy installation and operation.
Q: What are the benefits of using a high voltage energy storage system?
A: High voltage systems are more efficient in transferring energy and reducing losses. This results in better overall performance, particularly in commercial applications where energy demands are high.
Q: Is this system scalable for future expansion?
A: Yes, the 100kW-115kW energy storage system is designed to be scalable. Additional units can be integrated into the existing system as your energy needs grow, providing a future-proof solution for your business.
Q: What kind of maintenance is required for this system?
A: Our energy storage system is designed for minimal maintenance. Regular monitoring through the integrated energy management system will ensure optimal performance, and our support team is available for any service needs.
Q: Can this system be used as a standalone battery storage solution?
A: Absolutely. In addition to being integrated with commercial solar power systems, our energy storage solution can function independently as a battery storage facility, providing versatile options for energy management and backup power.
Contact Us
For more information on our 100kW-115kW High Voltage Lithium Battery Energy Power System or to discuss your specific energy storage needs, please contact us. Our team of experts is ready to assist you in finding the perfect solution for your commercial energy requirements.
