High Capacity 200kW Battery Energy Storage System

Efficient and Reliable Energy Solution

Introducing our cutting-edge High Capacity 200kW Battery Energy Storage System, the powerhouse solution you've been searching for to revolutionize your energy needs. Say goodbye to worrying about power outages or fluctuating energy costs – with our state-of-the-art system, you're in control.

Experience unparalleled reliability and efficiency with our advanced battery technology. Whether you're

The 200kWh Air-Cooled Energy Storage System (Model: FC-W-200kWh-100kW) internally
integrates DCDC energy storage/photovoltaic-side voltage transformation, supporting connection
to photovoltaic systems. It is capable of Real-time monitoring of smoke and temperature,
along with multiple-point real-time monitoring by BMS and EMS to ensure the system's
safe and reliable operation. The EMS system enables the storage, transfer, and exchange of
the energy between the storage device, the photovoltaic system, the grid, and the load, thus optimizing
the energy, improving the stability of the power supply system and the quality of the
power supply.

Efficient Solar Energy Solution: 200kW All-in-One System with LFP Battery

Unmatched Power Generation: Discover unparalleled energy efficiency with our 200kW all-in-one solar energy system. Designed to revolutionize power generation, this system harnesses the abundant energy of the sun to provide a sustainable and reliable power source for your large-scale projects.

Cutting-Edge LFP Battery Technology: Experience the future of energy storage with our advanced LFP battery technology. Engineered for maximum performance and durability, our lithium iron phosphate (LFP) batteries ensure seamless energy storage and distribution, even in the most demanding environments.

Seamless Integration and Scalability: Our 200kW all-in-one system offers seamless integration of solar panels and LFP battery storage, providing a comprehensive energy solution for your business or industrial needs. With scalability in mind, this system can be easily expanded to accommodate future growth and energy requirements.

PV
parameters
Max.Input power
50KW
100KW
Start-up voltage
135V
PV Max voltage
1000Vdc
PV rated voltage
620Vdc
MPPT operating voltage range
200 ~ 850 Vdc
MPPT Qty.
4
Qty. of single MPPT input channels
2
Max. Input current
30A
Max. short circuit current
40A
ESS
parameters
Rated power
100KWh
215KWh
Rated capacity
160Ah
280Ah
Rated voltage
614.4Vdc
768Vdc
Battery voltage range
537.6 ~ 691.2 Vdc
672~864Vdc
Rated charge/discharge current
80A
130A
Max. charge/discharge current
160A
280A
AC parameters
Rated output power
50KW
100KW
Max. input apparent power
60 KVA
110KVA
Grid-connected Max output apparent power
55 KVA
110KVA
Off-grid Max. output apparent power
55 KVA
110KVA
Max. output current
83A
166A
Rated voltage(input&output)
3L/N/PE; 220/380V;230/400V;240/415V
380VAC~
Grid frequency
50Hz/60Hz
50Hz/60Hz
THDu
<3%@ rated power& linear load
Efficiency
parameters
Max.PV conversion efficiency
98.8%
98.8%
EU efficiency
98.8%
98.8%
Ambient
parameters
Operating temperature
-25°C~55°C(45°Cderating)
-25°C~55°C(45°Cderating)
Storage temperature
-20°C~45°C
-20°C~45°C
Humidity
5~95%,no condensing
5~95%,no condensing
Altitude
2000m(2000m derating)
2000m(2000m derating)
Cooling mode
Smart air conditioner, smart fan
Smart air conditioner, smart fan
Other parameters
Dimension(W*H*D)
1100*1100*2000mm
1300*1235*2466mm
Weight
1300 kg
2500 kg
Ingress protection
IP54
IPX5
Communication mode
CAN, RS485, WiFi/LAN


Product Features:

  • Modular design with flexible configuration
  • Intelligent Energy Management System (EMS) with multiple management strategies
  • Seamless switching between STS and off-grid operation
  • Integrated components such as DC/DC, supporting photovoltaic integration
  • Battery system with hierarchical management, real-time monitoring, and dual-layer thermal insulation design
  • Multiple intelligent safety systems
  • Professional design and one-stop service
