21kWh Rack Mounted High Voltage Battery
Expand your solar energy independence with the 21kWh rack-mounted high-voltage battery. This advanced LiFePO4 battery (204.8V, 105Ah) efficiently stores excess solar energy, empowering your home during outages or periods of low sunlight. Maximize self-sufficiency, minimize grid reliance, and experience the peace of mind of clean, sustainable backup power. This reliable, long-life battery delivers exceptional performance for your solar energy needs.
|
Rated voltage
|
204.8V
|
|||||
|
Working voltage range
|
147.2-233.6V
|
|||||
|
Charge voltage
|
217.6-220.8V
|
|||||
|
Floating charge voltage
|
214.4-217.6V
|
|||||
|
Rated capacity
|
50AH
|
80AH
|
105AH
|
160AH
|
230AH
|
280AH
|
|
Energy
|
10.24KWH
|
16.37KWH
|
21.5KWH
|
32.76KWH
|
47.1KWH
|
57.34KWH
|
|
Rated charge current
|
25A
|
40A
|
50A
|
80A
|
115A
|
140A
|
|
Peak charge current
|
50A
|
80A
|
105A
|
160A
|
230A
|
280A
|
|
Rated discharge current
|
50A
|
80A
|
105A
|
160A
|
230A
|
280A
|
|
Peak discharge current
|
100A
|
160A
|
210A
|
320A
|
460A
|
460A
|
|
Charge temperature
|
0-55℃
|
|||||
|
Discharge temperature
|
-10-55℃
|
|||||
|
Optimum temperature
|
15-25℃
|
|||||
|
Cooling method
|
Natural cooling
|
|||||
|
Relative humidity
|
5%-95%
|
|||||
|
Altitude
|
≤2000M
|
|||||
|
Cycle Life
|
≥8000times@80%DOD，0.5C/0.5C，25℃
|
|||||
|
Communication interfaces
|
CAN2.0/RS485/Dry
|
|||||
|
Protection
|
Over temperature, over current, over-voltage, insulation, and other multiple protection
|
|||||
|
Display
|
LCD
|
|||||
|
Design lifetime
|
≥10 years
|
|||||
|
Certification
|
UN38.3/UL1973/IEC62619
|
|||||
|
Dimension（L*W*H）
|
600*600*1109MM
|
600*600*1287MM
|
600*600*1287MM
|
600*600*1465MM
|
600*660*1643MM
|
600*800*1643MM
|
|
Weight
|
205KG
|
255KG
|
275KG
|
385KG
|
465KG
|
565KG
|
|
Module module
|
51.2V50AH
|
51.2V80AH
|
51.2V105AH
|
51.2V160AH
|
51.2V230AH
|
51.2V280AH
|
|
Serial/Parallel
|
16S1P
|
16S1P
|
16S1P
|
16S1P
|
16S1P
|
16S1P
|
|
Module dimension
|
482.6*416.2*132.5MM
|
482.6*416.2*177MM
|
482.6*416.2*177MM
|
482.6*554*221.5MM
|
482.6*614*265.9MM
|
482.6*754*265.9MM
|
|
Module weight
|
30KG
|
41.5KG
|
46.5KG
|
72KG
|
90KG
|
114KG
|
|
Number of modules
|
4PCS
|
4PCS
|
4PCS
|
4PCS
|
4PCS
|
4PCS
|
|
Battery type
|
LiFePO4
|
LiFePO4
|
LiFePO4
|
LiFePO4
|
LiFePO4
|
LiFePO4
|
Power your off-grid lifestyle with confidence using our innovative 21kWh rack-mounted high voltage battery. This feature-packed lithium iron phosphate (LiFePO4) battery delivers exceptional performance, safety, and scalability, making it the perfect partner for your solar energy system.
Unmatched Advantages:
- Uninterrupted Power: Enjoy 21kWh of usable energy, keeping your appliances and electronics running smoothly even during outages or on low-sun days.
- Effortless Integration: The rack-mounted design seamlessly integrates with standard solar racking systems for a clean, organized installation.
- Optimized Efficiency: The 204.8V high voltage design minimizes cable losses, ensuring maximum power delivery to your devices.
- Reliable Output: The 105Ah capacity guarantees consistent power output, meeting your daily energy demands without worry.
- Built to Last: LiFePO4 chemistry offers superior safety, exceptional longevity, and impressive discharge rates compared to traditional lead-acid batteries.
- Solar Synergy: Specially designed to seamlessly integrate with your off-grid solar panels, storing clean, renewable energy for later use.
Reap the Benefits of Off-Grid Power:
- Energy Independence: Say goodbye to dependence on the grid and potentially reduce your electricity bills.
- Peace of Mind: Weather outages with confidence, knowing your home or business has a reliable backup power source.
- Scalable Solution: Easily expand your battery storage capacity as your energy needs grow in the future.
- Sustainable Future: Embrace clean energy solutions and contribute to a greener tomorrow by storing solar-generated power.
Invest in freedom and sustainability with our 21kWh rack-mounted high-voltage battery. Experience the power of solar energy independence today!
